Electrical and Electronic Circuits Kit 1 - Bachelor of Engineering Level 3
Academic Year: 2026 - 2027
This kit for ELN8304 is included in your course fees.
This Electrical and Electronic Circuits Kit 1 is required for the ELN8304 course and includes a comprehensive set of components necessary for various circuit experiments and projects. The kit features a selection of resistors, capacitors, inductors, potentiometers, and wiring essentials.
Kit Includes:
| Quantity |
Description |
| 2 |
1 Ω 1/2 Watt Resistor |
| 2 |
10 Ω 1/2 Watt Resistor |
| 2 |
22 Ω 1/2 Watt Resistor |
| 3 |
100 Ω 1/2 Watt Resistor |
| 2 |
220 Ω 1/2 Watt Resistor |
| 4 |
330 Ω 1/2 Watt Resistor |
| 4 |
470 Ω 1/2 Watt Resistor |
| 2 |
820 Ω 1/2 Watt Resistor |
| 5 |
1K Ω 1/2 Watt Resistor |
| 2 |
1.2K Ω 1/2 Watt Resistor |
| 3 |
2.2K Ω 1/2 Watt Resistor |
| 4 |
3.3K Ω 1/2 Watt Resistor |
| 3 |
4.7K Ω 1/2 Watt Resistor |
| 2 |
6.8K Ω 1/2 Watt Resistor |
| 2 |
9.1K Ω 1/2 Watt Resistor |
| 2 |
47K Ω 1/2 Watt Resistor |
| 3 |
100K Ω 1/2 Watt Resistor |
| 2 |
10 nF Ceramic Capacitor |
| 2 |
0.01 μF Capacitor (Ceramic and Electrolytic, 35V rating) |
| 2 |
1 μF Electrolytic Capacitor (35V rating) |
| 3 |
100 μF Electrolytic Capacitor (35V rating) |
| 3 |
220 μF Electrolytic Capacitor (35V rating) |
| 5 |
10mH Inductor - Wire Wound |
| 1 |
1 kΩ Potentiometer |
| 1 |
5 kΩ Potentiometer |
| 1 |
10 kΩ Potentiometer |
| 4 |
Connector Cables with Banana Plugs (5ft long, Red and Black) |
| 1 |
6ft Gauge 22 Solid Tinned Wire (Red) |
| 1 |
6ft Gauge 22 Solid Tinned Wire (Black) |
| 1 |
2ft Gauge 22 Solid Tinned Wire (Yellow) |
| 1 |
2ft Gauge 22 Solid Tinned Wire (Blue) |
| 1 |
2ft Gauge 22 Solid Tinned Wire (Brown) |
Total Number of items in Kit: 46
